El Diente
The El Diente has been DEAN’s topflight road bike for more than two decades, creating a benchmark for us that was hard to beat. The All New El Diente raises the stakes with a feature-packed design tailored to every rider's craving. Each tube we use is selected based on the rider’s size and performance. Additionally, it is constructed with the best quality aerospace 3/2.5 cold-worked and stress-relieved titanium. This formula converges to create a quick and lively road bike that not only feels fast, but will keep you comfortable whether you are knocking out a quick loop or doing an all-day challenge.
Price: Frame Starting at $3,700
Lead Time: 3 months from deposit
Contact: info@deanbikes.com
GEOMETRY
The stock El Diente geometry is a modernized version of our classic road racing bike. We have taken what we have learned over the years and updated the bike be fast with nimble handling all while allowing the rider to feel confident in every corner.
| El Diente | 46cm | 48cm | 52cm | 54cm | 56cm | 58cm | 60cm | 64cm |
|---|---|---|---|---|---|---|---|---|
| Stack [mm] | 505 | 522 | 541 | 553 | 574 | 593 | 615 | 638 |
| Reach [mm] | 360 | 372 | 374 | 379 | 384 | 398 | 408 | 415 |
| Eff. TT [mm] | 495 | 519 | 530 | 540 | 555 | 576 | 590 | 605 |
| Wheel Size | 700c | |||||||
| HTA [deg] | 70.5° | 71.5° | 72° | 72.75° | 73° | 73° | 73° | 73.5° |
| STA [deg] | 75° | 74.25° | 74° | 73.75° | 73.5° | 73.5° | 73.5° | 73.5° | Seat Tube Length [mm] | 430 | 450 | 475 | 490 | 530 | 560 | 580 | 610 |
| CS Length [mm] | 415 | 420 | ||||||
| Wheelbase [mm] | 977 | 979 | 980 | 982 | 992 | 1010 | 1031 | 1052 |
| BBD [mm] | 71 | |||||||
Technical Specifications
Tire Clearance: 700x32c
Rear Hub: 142x12
Bottom Bracket: T47x86mm
Headset: EC44/ZS44
Seattube: 27.2mm, 31.8 clamp
Brake: FM160
Material: Grade 9 Seamless CWSR 3/2.5 Titanium
